Quickturn Circuit Board Assembly
,Customized Design Circuit Board Assembly
,Quickturn Circuit Board Manufacturing
-
Product NameCustomized PCB Fabrication Quick Turn Prototype PCB Assembly Service
-
FeatureCustomized
-
Min Package01005
-
Profiling PunchingRouting/V-CUT/Beveling
-
High-end EquipmentFUJI NXT3/XPF Laminator
-
Minimum Finished Aperture0. 10mm
-
TestAOI/ X-Ray/Flying-Probe/Function Test
-
Min. Hole Size0.2mm, 4mil-laser Drill, 6mil, 0.1mm-1mm, 0.15mm
-
Place of OriginCHINA
-
Brand NameXHT
-
CertificationISO、IATF16949、RoSH
-
Model NumberXHT Prototype PCB Assembly-3
-
Minimum Order QuantityNO MOQ
-
Packaging DetailsCarton with foam bag
-
Delivery Time5-8 work days
-
Payment TermsT/T, Western Union, MoneyGram
-
Supply Ability600000＋ PCS/mouth
Cost Effectively Quick turn Prototype Circuit Board Assembly With Customized Design
Customized PCB Fabrication Quick Turn Prototype PCB Assembly Service
What is circuit PCB assembly service?
Printed circuit board assembly is the process of connecting the electronic components with the wirings of printed circuit boards. The traces or conductive pathways engraved in the laminated copper sheets of PCBs are used within a non-conductive substrate in order to form the assembly. Attaching the electronic components with the printed circuit boards is the concluding action before using the fully operational electronic device
Who are we?
- PCB assembly service manufacturer located in China.
- Over 600 total staff
- 25,000sqm production capacity
- Advanced automatic production equipments
- Offers various kinds PCBs, small to medium to mass quantity orders
- Major markets include domestic China, Asia, Europe and North America
- Customers include OEM/ODM factories, PCBA factories, EMS, trading companies
Technical Requirement for pcb assembly:
1) Professional Surface-mounting and Through-hole soldering Technology
2) Various sizes like 1206, 0805, 0603 components SMT technology
3) ICT(In Circuit Test),FCT(Functional Circuit Test) technology.
4) PCB Assembly With CE, FCC, Rohs Approval
5) Nitrogen gas reflow soldering technology for SMT.
6) High Standard SMT&Solder Assembly Line
7) High density interconnected board placement technology capacity.
Specification
| NO. | Items | Capabilities |
| 1 | Layers | 2-68L |
| 2 | Maximum machining size | 600mm*1200mm |
| 3 | Board thickness | 0.2mm-6.5mm |
| 4 | Copper thickness | 0.5oz-28oz |
| 5 | Min trace/space | 2.0mil/2.0mil |
| 6 | Minimum finished aperture | 0. 10mm |
| 7 | Maximum thickness to diameter ratio | 15:1 |
| 8 | Via treatment | Via, blind&buried via, via in pad, Copper in via … |
| 9 | Surface finish/treatment | HASL/HASL lead free, Chemical tin, Chemical Gold, Immersion gold Inmersion Silver/Gold, Osp, Gold Plating |
| 10 | Base Material | FR408 FR408HR, PCL-370HR;IT180A, Megtron 6(Panasonic);Rogers4350, Rogers4003, RO3003, Rogers/Taconic/Arlon/Nelco laminate with FR-4 material(including partial Ro4350B hybrid laminating with FR-4) |
| 11 | Solder mask color | Green.Black.Red.Yellow.White.Blue.Purple.Matte Green. Matte Black |
| 12 | Testing Service | AOI, X-Ray, Flying-Probe, Function Test, First Article Tester |
| 13 | Profiling Punching | Routing,V-CUT,Beveling |
| 14 | Bow&twist | ≤0.5% |
| 15 | HDI type | 1+n+1,2+n+2,3+n+3 |
| 16 | Min mechanical aperture | 0.1mm |
| 17 | Min laser aperture | 0.075mm |
FAQ
| Q: What is your inspection policy? How do you control the quality? XHT: In order to ensure the quality of PCB products, flying probe inspection is usually used; electrical fixtures, automatic optical inspection (AOI), BGA parts x-ray inspection, first article inspection ( FAI) etc. |
| Q: What service do you have? XHT: We provide turnkey solution including RD, PCB fabrication, SMT, final assembly,testing and other value-added service. |
| Q: What are the main products of your PCB/PCBA services? XHT: Our PCB/PCBA services are mainly for the industries including Medical, Automotive, Energy, Metering/Measurements, Consumer Electronics. |
| Q: Is XHT a factory or trade company? XHT:XHT is a factory with PCB factory located in Senzhen and SMT assembly factories in both Shenzhen and Chengdu. |
| Q: Can we inspect quality during production? XHT: Yes, we are open and transparent on each production process with nothing to hide. We welcome customer inspect our production process and check in house. |
| Q: How can we ensure our information should not let third party to see our design? XHT: We are willing to sign NDA effect by customer side local law and promising to keep customers data in high confidential level. |
Our products are sold all over the world, you can rest assured.
