XPF Laminator Circuit Board Manufacturing High Speed Prototype PCBA Samples
-
Highlight
Power Saving Circuit Board Manufacturing
,XPF Laminator Circuit Board Manufacturing
,Power Saving Prototype PCB Manufacturing
-
Product NameCircuit Board Manufacturing High Speed Prototype PCBA Samples
-
Min Package03015
-
High-end EquipmentFUJI NXT3/XPF Laminator
-
TestAOI/ X-Ray/Flying-Probe/Function Test
-
Base MaterialFR-4, Rogers, Aluminum, CEM-1 OR FR-4, FR4/FR1/ FR2/ FR3/ CEM1/ CEM3/ROGERS/ARLON/ISOLA
-
Min. Hole Size0.2mm, 4mil-laser Drill, 6mil, 0.1mm-1mm, 0.15mm
-
Min. Line Width3mi, 0.2mm, 0.15mm, 0.1 0mm, 0.075mm/0.075mm(3mil/3mil)
-
Solder Mask ColorBlue, White Black Yellow Green Red, Green, Yellow, Green Black Bule White
-
Place of OriginCHINA
-
Brand NameXHT
-
CertificationISO、IATF16949、RoSH
-
Model NumberXHT Prototype PCB Assembly-4
-
Minimum Order QuantityNO MOQ
-
Packaging DetailsCarton with foam bag
-
Delivery Time5-8 work days
-
Payment TermsT/T, Western Union, MoneyGram
-
Supply Ability600000＋ PCS/mouth
XPF Laminator Circuit Board Manufacturing High Speed Prototype PCBA Samples
XPF Laminator Circuit Board Manufacturing High Speed Prototype PCBA Samples
Technical Requirement for pcb assembly service:
1) Professional Surface-mounting and Through-hole soldering Technology
2) Various sizes like 1206, 0805, 0603 components SMT technology
3) ICT(In Circuit Test),FCT(Functional Circuit Test) technology.
4) PCB Assembly service With CE, FCC, Rohs Approval
5) Nitrogen gas reflow soldering technology for SMT.
6) High Standard SMT&Solder Assembly Line
7) High density interconnected board placement technology capacity.
Applications:
Like automotive applications, aerospace applications of PCB assembly service require extreme precision and durability. Jets and rockets often experience a lot of turbulence in the atmosphere, which means that ordinary rigid PCBs can be stressed enough to be damaged in the process. To solve this problem, most aerospace manufacturers use flexible PCBs that, in addition to being resistant to vibration damage, are lightweight and small.
In addition to being durable, aerospace PCB assembly service must be very high-functioning and precise, manufactured to the best of their ability to avoid technical issues. Since the electronics used in aerospace technology are critical to the safety of vehicles and their crews, it is critical that they function flawlessly.
Some of the more common aerospace applications for PCB assembly service include:
1. Monitoring equipment: Instrumentation, including accelerometers, pressure sensors, microphones, and torque and force sensors All use PCB assembly service as part of their basic functions. These products are used in the engines and cockpits of aircraft and rockets to monitor vehicle functions and communicate with ground control systems.
2. Test Equipment: In addition to its function as an aircraft, PCB assembly service are involved in the development and testing of aircraft. Test equipment that collects data during structural, vibration, and flight testing uses a PCB as its core. This data can be used to develop more efficient, efficient and safer aircraft.
Specification
| NO. | Items | Capabilities |
| 1 | Layers | 2-68L |
| 2 | Maximum machining size | 600mm*1200mm |
| 3 | Board thickness | 0.2mm-6.5mm |
| 4 | Copper thickness | 0.5oz-28oz |
| 5 | Min trace/space | 2.0mil/2.0mil |
| 6 | Minimum finished aperture | 0. 10mm |
| 7 | Maximum thickness to diameter ratio | 15:1 |
| 8 | Via treatment | Via, blind&buried via, via in pad, Copper in via … |
| 9 | Surface finish/treatment | HASL/HASL lead free, Chemical tin, Chemical Gold, Immersion gold Inmersion Silver/Gold, Osp, Gold Plating |
| 10 | Base Material | FR408 FR408HR, PCL-370HR;IT180A, Megtron 6(Panasonic);Rogers4350, Rogers4003, RO3003, Rogers/Taconic/Arlon/Nelco laminate with FR-4 material(including partial Ro4350B hybrid laminating with FR-4) |
| 11 | Solder mask color | Green.Black.Red.Yellow.White.Blue.Purple.Matte Green. Matte Black |
| 12 | Testing Service | AOI, X-Ray, Flying-Probe, Function Test, First Article Tester |
| 13 | Profiling Punching | Routing,V-CUT,Beveling |
| 14 | Bow&twist | ≤0.5% |
| 15 | HDI type | 1+n+1,2+n+2,3+n+3 |
| 16 | Min mechanical aperture | 0.1mm |
| 17 | Min laser aperture | 0.075mm |
Company Profile
XHT is a team with more than 20 years experience in the field. We owns abundant experiences for serving overseas customers from industrial automatic control, communication, medical, Auto and consumer electronics,etc. We test our product strictly to guarantee the quality to our customers. We accumulate high reputation during our cooperation.You will achieve following value-added services when you cooperate with us:
One-stop PCB/Turnkey PCB Assembly Service
Optimizing your PCB design during production
Satisfied quality with competitive prices
Instant response in both quotation and delivery
Increase your business with our powerful support
FAQ
| Q: WHAT IS YOUR TERMS OF PACKING? XHT: Generally, we pack our goods in neutral white boxes and brown cartons. |
| Q: WHAT IS YOUR MOQ? XHT: MOQ is SPQ normally, while it depends on your specific order. (Sample is available if the buyer can afford the shipping fee.) |
| Q: DO YOU TEST ALL YOUR GOODS BEFORE DELIVERY? XHT: 1. Our products are all original, and we will test the goods before shipment by professional machines like KEYSIGHT E4991A and KEYSIGHT E4980. 2. If The buyer need Test Report, we can send the product to anthoritative institution such as White horse Laboratories(SZ) Limited,Global Electronics Testing,etc. |
| Q: HOW DO YOU MAKE OUR BUSINESS LONG-TERM AND GOOD RELATIONSHIP? XHT: 1. We would like to offer sample if the buyer really want to make long-term relationship with us. 2. We keep good quality and competitive price to ensure our customers benefit. 3. We respect customers as our friend and sincerely do business and make friends with them,no matter where they come from. |
| Q: Do you support fast proofing? XHT: Yes, we support fast proofing within 3-7 days. |
Our products are sold all over the world, you can rest assured.
