Professional Green Multilayer EMS Circuit Board Assembly OEM Ems Pcba Solution One Stop Service
-
Highlight
Multilayer EMS Circuit Board
,Professional EMS Circuit Board
,Professional PCB Board Assembly
-
Min. Line Width3mi, 4mil, 0.1mm, 0.1mm(Flash Gold)/0.15mm(HASL), 0.1 0mm
-
Surface FinishingHASL, OSP, ENIG, HASL Lead Free, Immersion Gold
-
Copper Thickness1oz,0.5-2.0 Oz,1-3oz,0.5-5oz,0.5-4oz
-
Base MaterialFR4, Aluminium, TG, Rogers, CEM-1
-
Min. Line Spacing0.003", 4mil, 0.2mm, 0.15mm, 0.1mm4mil)
-
Board Thickness1.6mm, 0.5~3.2mm, 0.2-3.0mm, 0.3~2.5mm, 2.0m
-
Min. Hole Size0.25mm, 0.1mm, 0.2 Mm, 0.15-0.2mm, 0.1mm-1mm
-
Solder MaskBlue, Green. Red. Blue. White. Black.Yellow
-
Place of OriginChina
-
Brand NameXHT
-
CertificationISO、IATF16949、RoSH
-
Model NumberXHT-PCBA-9
-
Minimum Order QuantityLow MOQ
-
Packaging DetailsCarton with foam bag
-
Delivery Time1-2 weeks
-
Payment TermsT/T, Western Union, MoneyGram
Professional Green Multilayer EMS Circuit Board Assembly OEM Ems Pcba Solution One Stop Service
Printed Circuit Board/Multilayer board/Single-side pcb/Pcba/Dip Service
SMT
SMT patch processing will purchase components according to BOM, BOM provided by customers and confirm the PMC plan of production. After the preparatory work is completed, we will start SMT programming, manufacture laser steel mesh and solder paste printing according to the SMT process.
The components will be mounted on the circuit board through SMT mounter, and online AOI automatic optical detection will be carried out if necessary. After testing, the perfect reflow furnace temperature curve is set to let the circuit board flow through reflow welding.
After the necessary IPQC inspection, the DIP material can then be passed through the circuit board using the DIP process and then through wave soldering. Then it is time to carry out the necessary post-furnace process.
| Turnkey PCBA | PCB+components sourcing+assembly+package | ||||
| Assembly details | SMT and Thru-hole, ISO lines | ||||
| Lead Time | Prototype: 15 work days. Mass order: 20~25 work days | ||||
| Testing on products | Flying Probe Test, X-ray Inspection, AOI Test, functional test | ||||
| Quantity | Min quantity: 1pcs. Prototype, small order, mass order, all OK | ||||
| Files we need | PCB: Gerber files(CAM, PCB, PCBDOC) | ||||
| Files we need | Components: Bill of Materials(BOM list) | ||||
| Files we need | Assembly: Pick-N-Place file | ||||
| PCB panel Size | Min size: 0.25*0.25 inches(6*6mm) | ||||
| Max size: 20*20 inches(500*500mm) | |||||
| PCB Solder Type | Water Soluble Solder Paste, RoHS lead free | ||||
| Components details | Passive Down to 0201 size | ||||
| Components details | BGA and VFBGA | ||||
| Components details | Leadless Chip Carriers/CSP | ||||
| Components details | Double-sided SMT Assembly | ||||
| Components details | Fine Pitch to 0.8mils | ||||
| Components details | BGA Repair and Reball | ||||
| Components details | Part Removal and Replacement | ||||
| Component package | Cut Tape,Tube,Reels,Loose Parts | ||||
| PCB assembly | Drilling-----Exposure-----Plating-----Etaching & Stripping-----Punching-----Electrical Testing-----SMT-----Wave Soldering-----Assembling-----ICT-----Function Testing-----Temperature & Humidity Testing | ||||
1. Program and functional test and package by Free.
2. High quality: IPC-A-610E standard, E-test, X-ray, AOI test, QC, 100% functional test.
3. Professional service: PCB/FPC/Aluminium Making, SMT, DIP, Component Sourcing, OEM with 21 years experience.
4. Certifications: UL, 94v-0, CE, SGS, FCC, RoHS, ISO9001, ISO14001,IATF16949
Professional Green Multilayer EMS Circuit Board Assembly OEM Ems Pcba Solution One Stop Service
Introduction
We have a strong electronic component supply chain, we can offer competitive price for your BOM list.
Service
We specialize in providing comprehensive EMS solutions to meet the unique needs of our clients.
Our products are sold all over the world, you can rest assured.
