IPC Class II/III Inspection Standard Turnkey PCB Assembly with Mixed Assembly Method and CEM-3 Base Material
-
Highlight
IPC Class II/III PCB Assembly
,Mixed Assembly Method PCB Assembly
,CEM-3 Base Material PCB Assembly
-
Surface FinishHASL-lead Free
-
Laser Hole FillingYes
-
Thickness1.6mm Thickness
-
Additional ServicesDesign For Manufacturability (DFM), Component Sourcing, Box Build Assembly
-
Board TypeSingle-Sided, Double-Sided, Multi-Layer
-
Min Hole0.1mm
-
Inspection StandardIPC Class II/ IPC Class III
-
Material Precision0402+MCU Mm
-
Place of OriginChina
-
Brand NameXHT brand
-
CertificationCE,RoHs,UL,FCC,ISO
-
Model NumberXHTROBOT01
-
Document
-
Minimum Order Quantity1
-
PriceUSD0.1-100/PCS
-
Packaging Detailsgreen energy brown packing, Eco friendly packing
-
Delivery Time5-8 work days
-
Payment TermsL/C, T/T
-
Supply Ability500000
IPC Class II/III Inspection Standard Turnkey PCB Assembly with Mixed Assembly Method and CEM-3 Base Material
Turnkey Printed Circuit Board Assembly
Product Description
XHT offers high-quality Turnkey PCB Assembly, ensuring durability, precision, and compliance with industry standards. Our 1.6mm standard PCB thickness provides the perfect balance between sturdiness and flexibility, suitable for various applications.
In addition to PCB assembly services, we offer:
- Design for Manufacturability (DFM): Optimizes PCB designs for cost-effective production.
- Component Sourcing: High-quality components at competitive prices.
- Box Build Assembly: Full end-to-end PCB assembly solution, integrating PCBs into finished products.
With strict quality control, we adhere to IPC Class II & IPC Class III standards and accommodate a minimum hole size of 0.1mm for intricate designs. Our turnkey solutions streamline manufacturing from prototyping to mass production.
Features & Technical Specifications
| Feature | Details |
|---|---|
| Product Name | Turnkey Printed Circuit Board Assembly |
| Board Type | Single-Sided, Double-Sided, Multi-Layer |
| PCB Thickness | 1.6mm |
| Min Hole Size | 0.1mm |
| Surface Treatment | HASL, HASL-lead Free, OSP |
| Component Type | SMD, Through-Hole, Mixed |
| Material Precision | 0402+MCU mm |
| Inspection Standard | IPC Class II / IPC Class III |
| Laser Hole Filling | Yes |
| SMT Production Line | 14 |
Applications
XHT Turnkey PCB Assembly (Model: XHTROBOT01) is ideal for various industries including:
-
Electronics (consumer & industrial devices)
-
Automotive (ECUs, sensors, and modules)
-
Aerospace (high-reliability applications)
-
Medical Equipment (precision electronics)
-
Renewable Energy (BMS, inverters, controllers)
Certifications: CE, RoHs, UL, FCC, ISO
Customization Options
| Customization | Details |
| Brand Name | XHT brand |
| Model Number | XHTROBOT01 |
| Base Material | FR-4, CEM-1, CEM-3 |
| PCB Assembly Method | Mixed, BGA, SMT, Through-hole |
| Surface Finish | OSP, HASL-lead Free |
| MOQ | 1 piece |
| Price Range | USD 0.1 - 100 per piece |
| Packaging | Eco-friendly packing |
| Delivery Time | 5-8 workdays |
| Payment Terms | L/C, T/T |
| Supply Ability | 500,000 units per month |
Support & Services
Our Product Technical Support Team is available to assist with:
-
Troubleshooting technical issues
-
Guidance on assembly processes
-
Design consultation for optimization
Packing & Shipping
| Packing | Shipping |
| Packaging Details | Anti-static bags, protective cushioning in cardboard boxes |
| Shipping Methods | Reliable courier services with tracking number provided |
| Estimated Delivery | 5-8 workdays (varies by destination) |
FAQ
| Question | Answer |
| What is the brand name of the PCB Assembly product? | XHT brand |
| What is the model number? | XHTROBOT01 |
| Where is it manufactured? | China |
| What certifications does it have? | CE, RoHs, UL, FCC, ISO |
| What are the payment terms? | L/C, T/T |
For more information, contact us at xht1@xhtpcbaodm.com or call +86 13544250291.
Our products are sold all over the world, you can rest assured.
