OEM One Stop Service Beveling Quick Turn PCB Boards For Wide Applications
-
Highlight
Beveling Quick Turn PCB Boards
,OEM Quick Turn PCB Boards
,Beveling Quick Turn PCB Assembly
-
Product NameOEM ODM Quick Turn Electronic Control Board Main PCBA Service Customized
-
FeatureOEM/ODM/PCBA
-
High-end EquipmentFUJI NXT3/XPF Laminator
-
MaterialFR4/M4/M6/Rogers/TU872/IT968
-
Lead Time3-7 Working Days
-
TestAOI/SPI/XRAY/First Article Inspection
-
Place of OriginCHINA
-
Brand NameXHT
-
CertificationCE、RoSH、ISO
-
Model NumberXHT Quick Turn PCB Assembly-7
-
Minimum Order Quantity1k
-
Packaging DetailsCarton with foam bag
-
Delivery Time5-8 work days
-
Payment TermsT/T, Western Union, MoneyGram
OEM One Stop Service Beveling Quick Turn PCB Boards For Wide Applications
OEM ODM Quick Turn Electronic Control Board Main PCBA Service Customized
Advantages of XHT:
1. As a one-stop service shop, satisfied services will start from your inquiry to after-sales.
2. Free design stack-up service, modify until you are satisfied.
3. Each process is monitored by specialized quality inspection personnel to detect problems in time and solve them as soon as possible.
4. Expedited service is supported.
5. More than ten years of Main PCBA Service experience.
SMT Lines
Our company currently has 12 high speed SMT lines, 7 wave soldering production lines and 10 post-DIP soldering lines. We can make special fixtures according to customer requirements and product conditions to ensure product reliability and effectively improve plug-in efficiency.
Our DIP post-welding personnel have rich experience for Main PCBA service, and have formulated detailed standardized operation guidelines and SOP operation instructions to meet the high-quality requirements of high-end customers.
Specification
| NO. | Items | Capabilities |
| 1 | Layers | 2-68L |
| 2 | Maximum machining size | 600mm*1200mm |
| 3 | Board thickness | 0.2mm-6.5mm |
| 4 | Copper thickness | 0.5oz-28oz |
| 5 | Min trace/space | 2.0mil/2.0mil |
| 6 | Minimum finished aperture | 0. 10mm |
| 7 | Maximum thickness to diameter ratio | 15:1 |
| 8 | Via treatment | Via, blind&buried via, via in pad, Copper in via … |
| 9 | Surface finish/treatment | HASL/HASL lead free, Chemical tin, Chemical Gold, Immersion gold Inmersion Silver/Gold, Osp, Gold Plating |
| 10 | Base Material | FR408 FR408HR, PCL-370HR;IT180A, Megtron 6(Panasonic);Rogers4350, Rogers4003, RO3003, Rogers/Taconic/Arlon/Nelco laminate with FR-4 material(including partial Ro4350B hybrid laminating with FR-4) |
| 11 | Solder mask color | Green.Black.Red.Yellow.White.Blue.Purple.Matte Green. Matte Black |
| 12 | Testing Service | AOI, X-Ray, Flying-Probe, Function Test, First Article Tester |
| 13 | Profiling Punching | Routing,V-CUT,Beveling |
| 14 | Bow&twist | ≤0.5% |
| 15 | HDI type | 1+n+1,2+n+2,3+n+3 |
| 16 | Min mechanical aperture | 0.1mm |
| 17 | Min laser aperture | 0.075mm |
Company Profile
XHT has the capability to manufacture PCB ranging from basic single sided boards up to forty layers, and provide one stop turnkey services, including PCB manufacture, Main PCBA service, components sourcing and function testing. With one-stop solution, high-end product structure, professional product development and manufacturing technology, stable quality performance and well management system. XHT has established long-term and stable cooperate relations with the world's leading communication equipment, aerospace electronics and medical equipment manufacturers.
FAQ
| Q: What are the main products of your PCB/PCBA services? XHT: Automotive, Military, Aerospace, Industry Control, Medical care, IOT, Smart Home, Robot, Auto parts, Camera, UAV. |
| Q: What is your minimum order quantity (MOQ)? XHT: Our MOQ is 1 PCS, we are able to handle Small as well as large volume production with flexibility. |
| Q: Are you factory? XHT: yes |
| Q: How about the shipping cost? XHT: The Shipping cost depends on the destination, the weight and volume of the goods as well as the quotation of DHL/FEDEX/ freight forwarder at that time. You can inform us of the transportation way you need before placing an order. |
Our products are sold all over the world, you can rest assured.
