FR4 Pcb Manufacturer Printed Circuit Board PCB Multilayer PCB Fabrication Double Side PCB Fabricator

FR4 Pcb Manufacturer Printed Circuit Board PCB Multilayer PCB Fabrication Double Side PCB Fabricator

Brand Name:	XHT
Model Number:	XHT-FR-4 PCB Manufacturing-6
MOQ:	Low MOQ
Price:	US$ 1-5/Pcs
Delivery Time:	5-8 day
Payment Terms:	T/T, Western Union,

Detail Information

Product Description

Detail Information

Place of Origin:

China

Certification:

ISO、IATF16949、RoSH

Product Name:

FR4 Pcb Manufacturer Printed Circuit Board PCB Multilayer PCB Fabrication Double Side PCB Fabricator

Feature:

PCB Manufacture

Board Thickness:

0.2mm-6.5mm

High-end Equipment:

FUJI NXT3/XPF Laminator

Shape:

Retangular/Round/Slots/Cutouts/Complex/Irregular

Test:

AOI/ X-Ray/Flying-Probe/Function Test

Other Service:

Components Purchase /Assembly/Custom Packaging

Packaging Details:

Carton with bubble bag

Supply Ability:

100000pcs/day

Highlight:

FUJI NXT3 PCB Board Assembly

Prototype PCB Board Assembly

Customized PCB Assembly Services

Product Description

FR4 Pcb Manufacturer Printed Circuit Board PCB Multilayer PCB Fabrication Double Side PCB Fabricator

Introduction

Our company established in 2004, has become a trusted name in the EMS industry, strategically located in Huizhou, Guangdong province, near the bustling hub of Shenzhen.

With a landscape of 20,000 square meters, our facilities are equipped to cater to a diverse range of customers across various sectors, from consumer electronics to medical devices, automotive components, industrial equipment, power systems, new energy solutions, and communication devices.

Our comprehensive EMS/ODM/OEM services, including electronic system design, prototype development, PCB manufacturing, assembly, and rigorous testing, ensure top-notch quality, competitive pricing, and punctual delivery.

We have a strong electronic component supply chain, we can offer competitive price for your BOM list.

we've implemented a complete MES (Manufacturing Execution System) covering raw material acceptance, SMT surface mounting, DIP plug-in, and stringent product functional testing.

This system allows real-time monitoring and data tracing of any abnormal conditions during production, ensuring product integrity and full process traceability.

Our monthly production capacity of 600 million points ensures top-notch quality and timely delivery.

Service

We specialize in providing comprehensive EMS solutions to meet the unique needs of our clients.

Here's a glimpse of the services we offer:

1.Electronic Components Supply.

2.PCB Manufacturing.

3.PCB Assembly.

4.Box Building.

We have a strong electronic component supply chain, we can offer competitive price for your BOM list.

Advantages of XHT

ICT(In Circuit Test),FCT(Functional Circuit Test) technology
PCB Assembly service With CE, FCC, Rohs Approval
Nitrogen gas reflow soldering technology for SMT
Technical Requirement for PCB Assembly service
Professional Surface-mounting and Through-hole soldering Technology
Various sizes like 1206, 0805, 0603 components SMT technology

PCB Capacities and Technical Specification

NO.	Items	Capabilities
1	Layers	2-68L
2	Maximum machining size	600mm*1200mm
3	Board thickness	0.2mm-6.5mm
4	Copper thickness	0.5oz-28oz
5	Min trace/space	2.0mil/2.0mil
6	Minimum finished aperture	0. 10mm
7	Maximum thickness to diameter ratio	15:1
8	Via treatment	Via, blind&buried via, via in pad, Copper in via …
9	Surface finish/treatment	HASL/HASL lead free, Chemical tin, Chemical Gold, Immersion gold Inmersion Silver/Gold, Osp, Gold Plating
10	Base Material	FR408 FR408HR, PCL-370HR;IT180A, Megtron 6(Panasonic);Rogers4350, Rogers4003, RO3003, Rogers/Taconic/Arlon/Nelco laminate with FR-4 material(including partial Ro4350B hybrid laminating with FR-4)
11	Solder mask color	Green.Black.Red.Yellow.White.Blue.Purple.Matte Green. Matte Black
12	Testing Service	AOI, X-Ray, Flying-Probe, Function Test, First Article Tester
13	Profiling Punching	Routing,V-CUT,Beveling
14	Bow&twist	≤0.5%
15	HDI type	1+n+1,2+n+2,3+n+3
16	Min mechanical aperture	0.1mm
17	Min laser aperture	0.075mm

Company Profile

XHT focuses on one-stop service like research and development of sample making, batch PCB Assembly Service, test:

SMT production line: 14 SMT production lines.
Fast delivery: 8 hours of expedited delivery, with an accurate delivery rate of more than 95% within 48 hours.
Minimum mount: 03015,01005,0201,0402.
One-stop hardware innovation platform: PCB fabrication, PCB assembly, component selection.
High-end equipments: FUJI XPF, NXT3, AIMEX, AOI/SPI/XRAY/ First article inspection, etc.
Full BOM material selection: more than 60,000 kinds of common electronic components are in stock.
