HASL Lead Free Multilayer Circuit Board Manufacturing Double Sided PCB Fabrication

HASL Lead Free Multilayer Circuit Board Manufacturing Double Sided PCB Fabrication

Brand Name:	XHT
Model Number:	XHT-FR-4 PCB Manufacturing-8
MOQ:	Low MOQ
Price:	US$ 1-5/Pcs
Delivery Time:	5-8 day
Payment Terms:	T/T, Western Union,

Detail Information

Product Description

Detail Information

Place of Origin:

China

Certification:

ISO、IATF16949、RoSH

Product Name:

HASL Lead Free Multilayer Circuit Board Manufacturing Double Sided PCB Fabrication

Feature:

PCB Manufacture And Assembly

Maximum Machining Size:

600mm*1200mm

Profiling Punching:

Routing/V-CUT/Beveling

High-end Equipment:

FUJI NXT3/XPF Laminator

Test:

AOI/ X-Ray/Flying-Probe/Function Test

Other Service:

Components Purchase /Assembly/Custom Packaging

Packaging Details:

Carton with bubble bag

Supply Ability:

100000pcs/day

Highlight:

HASL Circuit Board Manufacturing

Lead Free Circuit Board Manufacturing

Multilayer Prototype PCB Assembly

Product Description

HASL Lead Free Multilayer Circuit Board Manufacturing Double Sided PCB Fabrication

PCB Capability & Technical Specification

NO.	Items	Capabilities
1	Layers	2-68L
2	Maximum machining size	600mm*1200mm
3	Board thickness	0.2mm-6.5mm
4	Copper thickness	0.5oz-28oz
5	Min trace/space	2.0mil/2.0mil
6	Minimum finished aperture	0. 10mm
7	Maximum thickness to diameter ratio	15:1
8	Via treatment	Via, blind&buried via, via in pad, Copper in via …
9	Surface finish/treatment	HASL/HASL lead free, Chemical tin, Chemical Gold, Immersion gold Inmersion Silver/Gold, Osp, Gold Plating
10	Base Material	FR408 FR408HR, PCL-370HR;IT180A, Megtron 6(Panasonic);Rogers4350, Rogers4003, RO3003, Rogers/Taconic/Arlon/Nelco laminate with FR-4 material(including partial Ro4350B hybrid laminating with FR-4)
11	Solder mask color	Green.Black.Red.Yellow.White.Blue.Purple.Matte Green. Matte Black
12	Testing Service	AOI, X-Ray, Flying-Probe, Function Test, First Article Tester
13	Profiling Punching	Routing,V-CUT,Beveling
14	Bow&twist	≤0.5%
15	HDI type	1+n+1,2+n+2,3+n+3
16	Min mechanical aperture	0.1mm
17	Min laser aperture	0.075mm

We are PCB Fabrication & PCB Assembly Professional Manufacturer

Introduction

Our company established in 2004, has become a trusted name in the EMS industry, strategically located in Huizhou, Guangdong province, near the bustling hub of Shenzhen.

With a landscape of 20,000 square meters, our facilities are equipped to cater to a diverse range of customers across various sectors, from consumer electronics to medical devices, automotive components, industrial equipment, power systems, new energy solutions, and communication devices.

Our comprehensive EMS/ODM/OEM services, including electronic system design, prototype development, PCB manufacturing, assembly, and rigorous testing, ensure top-notch quality, competitive pricing, and punctual delivery.

We have a strong electronic component supply chain, we can offer competitive price for your BOM list.

we've implemented a complete MES (Manufacturing Execution System) covering raw material acceptance, SMT surface mounting, DIP plug-in, and stringent product functional testing.

This system allows real-time monitoring and data tracing of any abnormal conditions during production, ensuring product integrity and full process traceability.

Our monthly production capacity of 600 million points ensures top-notch quality and timely delivery.

Service

We specialize in providing comprehensive EMS solutions to meet the unique needs of our clients.

Here's a glimpse of the services we offer:

1.Electronic Components Supply.

2.PCB Manufacturing.

3.PCB Assembly.

4.Box Building.

We have a strong electronic component supply chain, we can offer competitive price for your BOM list.

FR-4 Rogers4350 Rigid Flex RF PCB Board Chrome Plating Ultrasonic Driver PCBA 5

FR-4 Rogers4350 Rigid Flex RF PCB Board Chrome Plating Ultrasonic Driver PCBA 1

HASL Lead Free SMT Multilayer PCB Manufacturing 0

FAQ

Q: What is your minimum order quantity (MOQ)?
XHT: Our MOQ is 1 PCS, we are able to handle Small as well as large volume production with flexibility.

Q: Are you factory?
XHT: Our factory is located in Building 6, Fuyuan industrial park, Qiaotang road, Fuyong street, Shenzhen city, China.

Q: How about the shipping cost?
XHT: The Shipping cost depends on the destination, the weight and volume of the goods as well as the quotation of DHL/FEDEX/ freight forwarder at that time. You can inform us of the transportation way you need before placing an order.

Q: How can we guarantee quality?
XHT: Always a pre-production sample before mass production;
